Parent and marketing subsidiary
The official profile identifies 仨亿电器股份有限公司 as the parent and 上海仨亿奕迈科技有限公司 as the Shanghai subsidiary established in 2020. Shanghai is described as the marketing centre; 2020 is not assigned to every factory.
Wenling East New District 23rd Street
SAYI: choose YMF, BMF or a separate scroll package
Distinguish the works and supply company, compare actual model dimensions, and agree the control, air quality and offered duty.
SAYI · WENLING WORKS · SHANGHAI MARKETING
Separate the company, manufacturing site and ordered machine
Manufacturing locations
The profile describes Wenling’s Eastern New District production base and a screw-compressor works in Luojing, Baoshan, Shanghai. Agree the actual manufacturing works and supplying legal entity in the order.
The group describes compressors, blowers, combustion/baking components and integrated equipment. Historical area, staffing, equipment and 2019 sales statements do not establish present compressor production capacity.
Y IS A FAMILY NAME · YMF IS A SPECIFIC CONTROL SELECTION
Read the starting-method column before choosing a drive
YMF: PM variable speed
The selected Y-series page publishes permanent-magnet variable-frequency starting. Its 8 bar rows include YMF8-8, YMF11-8, YMF15-8, YMF22-8 and YMF37-8.
See YMF model duty →BMF: also published as PM variable speed
The B-series title is general, but the table’s starting column also says permanent-magnet variable-frequency. The letter B alone is not evidence of fixed-speed operation.
See BMF confirmed rows and clarifications →Y fixed-speed: a separate table
The company also publishes YPF/YLF fixed-speed equipment. YLF22-8 lists star-delta starting, whereas the existing Y selection here is YMF. Do not mix their drive, envelope or motor data.
For variable-speed selection, ask for minimum stable demand, turndown, low-load control and allowable stop/start duty. A general energy-saving statement is not a measured saving for your load profile.
SAME 22 kW DUTY · DIFFERENT PACKAGE ENVELOPES
Compare the complete model, not just its motor rating
| Exact model | Motor / volume flow | Outlet / L × W × H | Mass |
|---|---|---|---|
| YMF8-8 | 7.5 kW · 1.05 m³/min | G3/4 · 930 × 680 × 916 mm | 190 kg |
| BMF8-8 | 7.5 kW · 1.05 m³/min | G3/4 · 930 × 680 × 920 mm | 185 kg |
| YMF22-8 | 22 kW · 3.3 m³/min | G1 · 1200 × 820 × 1150 mm | 370 kg |
| BMF22-8 | 22 kW · 3.3 m³/min | G1 · 1200 × 840 × 1150 mm | 400 kg |
| YMF37-8 | 37 kW · 6.3 m³/min | G1½ · 1370 × 950 × 1360 mm | 560 kg |
Values are the manufacturer’s volume-flow table entries. Obtain pressure convention and flow/test reference; no independently measured FAD or other-pressure performance is asserted. Service/removal clearances and shipment dimensions are separate from the package envelope.
OIL-FREE SCROLL · A SEPARATE COMPRESSOR CATEGORY
Define module capacity and the quality at the receiving point
What to ask for the actual package
- Selected model’s motor/package input, pressure and delivered flow with test/reference conditions.
- Number of scroll modules, sequencing, permitted operating cycle and capacity with a module stopped.
- Receiver, dryer and filter scope; required oil, moisture and particle quality.
- Cooling, ambient limits, maintenance access and replacement-module procedure.
The page material obtained contains package photographs without a usable numerical table. Screw-machine ratings do not apply to these scroll machines. A modular photo does not prove N+1 standby.
Oil-free family wording is not a current ISO 8573-1 Class 0 certificate or evidence of dry, particle-free, food-approved air.
Review scroll supply and acceptance →Give SAYI a duty that can be quoted and compared
Demand at the process
Point-of-use pressure, pipe losses, simultaneous users, average/peak reference flow, shifts and electrical supply.
Selected control and package
Exact model, motor/drive, capacity/input at your duty, speed/load envelope, cooling limits and all included treatment.
Installation and acceptance
Package/electrical drawings, access, condensate handling, protections, test basis and receiving-point air quality.
Delivery and service
Manuals, consumables/spares, destination documents, commissioning, warranty commencement/exclusions and service responsibility.
Questions before choosing the model
Is every Y-series machine variable speed?
No. The official catalogue separates Y fixed-speed YPF/YLF machines from PM variable-speed YMF machines. Use the complete model and control sheet.
Can BMF22-8 use YMF22-8 installation dimensions?
No. Although their printed power, pressure and flow match, the BMF row is wider and heavier. Obtain the actual model drawing and service clearance.
Does an SF22-8 photo establish a 22 kW, 8 bar duty?
The photo establishes a visible identifier. Obtain its numerical datasheet instead of decoding the name, and agree delivered flow and air-quality acceptance.
Send the complete code and actual air demand
Choose YMF, BMF or scroll and include process pressure, reference flow, running pattern and required outlet quality.
Prepare a SAYI RFQSpecification pages
Specification pages for SAYI product types
| Duty | Write on the RFQ |
|---|---|
| How to specify an air compressor | If the RFQ only says “compressor, China”, a plant cannot price it. Start with architecture, then the duty point, then the papers. |
| 75 kW 8 bar rotary screw compressor | 75 kW at 8 bar(g) is a common plant-air point. FAD is not a brochure range — it is the flow at that pressure, after the cooler, for the voltage you actually run. |
| 110 kW 10 bar rotary screw compressor | 10 bar(g) is not 8 bar with a different sticker. FAD falls as pressure rises. Write 110 kW and 10 bar together, then the flow you need at that point. |
| 22 kW VSD screw compressor | 22 kW VSD is a flow band, not a single nameplate FAD. The plant needs min/max flow at the working pressure, or it will quote a fixed-speed machine with an inverter sticker. |
